EPE L Section
L-section is extruded L-shaped profile available in continuous length which finds application as a packaging product for electronic products, UPS, Invertors, furniture etc. Fabricated L-profile can also be made available. L-section is available in standard Size of L-45 and L-55 & L-70mm with length of 2Mtrs each. Technical Specifications of “SPICELL" Micro Cellular EPE Sections.
Property
|
Unit
|
Value
|
Density
|
Kg / M³ |
22 - 35
|
Tensile Strength
|
Kg / cm² |
2.55 - 6.00
|
Elongation
|
%
|
45 - 125
|
Tear Strength
|
GMF
|
150 Min
|
Compression Set
|
%
|
10 Max
|
Compression Strength at 10% Deformation
|
Kg / cm² |
0.05 - 0.20
|
| Water Aborption after 96 hrs, at 27°C |
% By Vol
|
0.01 - 0.05
|
Buoyancy
|
Kg / M³ |
920 - 940
|
Chemical Oil Resistance
|
|
Excellent |
Working Temperature
|
°C |
(- ) 30 to (+)70 |
Thermal Conductivity
|
K.Cal / M hr. °C |
0.025 - 0.032 |
All tests are carried out as per ASTM Standards. Technical specifications given above indicate attributes of products and are given in good faith and can vary depending upon test and climatic conditions. Technical specifications are subject to change without prior notice.
|
